hot sale 6kva air-cooled single phase diesel generator made in china
- TAIYAO
TYD6000SL
- Original hot sale 6kva air-cooled single phase diesel generator made in china
- One set hot sale 6kva air-cooled single phase diesel generator made in china
- Negotiation
- Within 5 working days
- paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
- 184
-
Shandong Brawny Industrial Co.,Ltd2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
Product Description
hot sale 6kva air-cooled single phase diesel generator made in china
Product Description
1.Features
* Max. Output power is 5kVA
* Low noise design, 72 dB (A)/7m
* Light weight and compact, only 170kg
* A full tank of fuel can last for 9 constant hours
* "E" indicate electric starter (Optional)
* Optional: Battery, Wheels, Handles and supporting legs.
2.Data & standard
Model |
TYD6000SL |
|
Rated frequency (Hz) |
50HZ |
60HZ |
Rated output (kVA) |
4.5KVA |
5.0KVA |
Max. output (kVA) |
5.0KVA |
6.0KVA |
Rated Voltage (V) |
110,120,220,230,240,110/220,120/240 |
|
Rated rotation speed (r/min) |
3000RPM |
3600RPM |
Phase NO. |
Single phase or three phase (optional ) |
|
Power factor (Cos Φ) |
1 |
|
Insulation Grade |
B |
|
Pole number |
2 |
|
Excitation mode |
Self-excitation & constant voltage (AVR) |
|
Panel Type |
General Panel |
|
DC12V output |
Connection pole output |
|
Overall dimension(L×W×H)(mm) |
955*565*760 |
|
Dry weight(kg) |
165 |
|
Working assorting weight (Kg) |
170 |
|
Noise level(7m)dB(A) |
72 |
|
Structure type |
Silent type |
|
Engine Model |
186FA |
|
Engine Type |
Single-cylinder,vertical,air-cooled,4-stroke,direct injection |
|
Cylinder NO.-bore×stroke (mm) |
1-86×72 |
|
Displacement |
418 |
|
Rated power [KW/(r/min)] |
6.4KW/3000 |
7.0KW/3600 |
Compression ratio |
19:01 |
|
Rated rotation speed (r/min) |
3000 |
3600 |
Combustion system |
Direct injection |
|
Cooling system |
Air cooled |
|
Lubrication system |
Pressure splashed |
|
Starting system |
Electric starter |
|
Fuel type |
0#(summer)-10#(winter)-35#(chillness)diesel |
|
Lube oil brand |
CD grade or SAE10W-30,15W-40 |
|
Lube capacity (L) |
1.65 |
|
Starting motor capacity (V-kW) |
12V 0.8kW |
|
Charging generator capacity (V-A) |
12V 3A |
|
Fuel consumption (g/kW.h) |
≤201 |
≤210 |
Fuel tank capacity (L) |
15 |
|
Continuous running time (hr) |
6 |
|
Packaging & Shipping
Diesel engine for universal usage sale packing:Carton
Shipping Detal: 10~30 days after receipt of 30% advance payment as deposite.
1. Q: Are you factory or trading company?
A: We are factory. We have 20 years manufacturing experience.
2. Q: What about the payment terms?
A: Usually, we accept T/T or L/C. 30% deposit first, 70% balance against the copy of B/L. Or you can adopt Escrow by hot sale 6kva air-cooled single phase diesel generator made in china so that you will have a guarantee for payment if we do not send goods.
3. Q: How long for delivery?
A: Usually, it takes 10-30 days after deposite, anyhow, it depends on the order details.
♠ Chongqing Taiyao Technology CO., Ltd., located in chongqing banan boundary stone industrial park, our factory is specialized in engine developing, manufacturing and trading.
♠ Our main products are gasoline/diesel engine, gasoline/diesel generator, water pump and power tiller. Companies adhering to the "excellent manufacturing quality, fine management and operation; elaborate the development and the market, sincere cooperation create brand" theory, which has provided global customers with competitive products and services.
♠ Most our products have achieved CE, ISO9001. Hope we have chance to build long term business relationship.
BACK TO HOMEPAGE
The air-cooled diesel generator can have optional wheels and hand kits, Electric start or manual starting.Small-sized diesel generator sets includes open type and silent type.Our hot sale 6kva air-cooled single phase diesel generator made in china adopt different diesel engines and brushless generators.Generally adopt 1-cylinder&4-stroke&air-cooled engine, low fuel consumption, high reliability;It is easy to maintain as adopting brushless A.C.Generator and CDI ignition system.
JHSBJDHV
air-cooled diesel generator are quick-starting, stable-running, little vibration, low noise, light weight, small volume, compact structure, suitable for areas on mining, factory, working on field, engaging in construction and army as movable power or electric power in ship, hot sale 6kva air-cooled single phase diesel generator made in china also suitable for areas on animal husbandry, fishery, forest, orchard, guesthouse and business as standby power.
JSHFDKJ
