Portable 5kw Water Cooled Diesel Marine Generator
- OUMA
OM5CYZ
- Original Portable 5kw Water Cooled Diesel Marine Generator
- One set Portable 5kw Water Cooled Diesel Marine Generator
- Negotiation
- Within 5 working days
- paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
- 121
-
Shandong Brawny Industrial Co.,Ltd2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
Product Description
In China, OUMA is the leader in the marine generator industry as a nominated supplier and over50% market share in China in fields of excursion boats, yachts, China Marine Bureau, ChinaFishery Administration, etc.
Equipped with heat exchanger, water cooled silencer, sea water retainer, remote control panel.
Compact structure, small dimension,light weight, low noise 60dBA at 7 m
Special structure design, perfect portability.
Unique design, easy installation and maintenance
Cold rolled steel or tainless steel enclosure, elegant appearance, water and dust proof, perfect protection to ensure reliable operation of the genset. Removable canopy fastened by buckles, make regular maintenance and repair so easy.
Water cooled
OUMA unique water cooled structure, engine and muffler are cooled by externally circulated sea water or river water, reduce temperature in the compartment of the yacht.
Filtration system
Water filter prevent dirty impurities, effectively protect the engine.
Control system
Remote control panel with cable, complete protection, alarm and shutdown to high water temperature, low oil pressure, low/over speed, low/high AC/DC voltage, low/high frequency, etc.
Specification:
| Generator Set | Model | OM5CYZ |
| Brand | OUMA | |
| Canopy material | Cold rolled steel | |
| Rated power(KW) | 5 | |
| Rated voltage(V) | 230 | |
| Rated current(A) | 23 | |
| Rated frequency(Hz) | 50 | |
| Waveform distortion | Sinewave, distortion ≤5% | |
| Noise level(dB@7m) w/100% load | 65 | |
| Battery(12V-Ah) | 12V36AH | |
|
Overall dimension (L×W×H)(mm) |
755×510×550 | |
| Overall weight(kg) | 180 | |
| Fuel tank capacity(L) | Share fuel tank with marine vehicle | |
| Preheat for low temperature | Available | |
| Diesel Engine | Model | OM188SVT |
| Brand | OUMA | |
| Power output(KW) | 5.5 | |
| Type | Single cylinder, vertical, four stroke,water cooled | |
| Displacement(L) | 0.416 | |
| Bore×Stroke(mm) | 88×90 | |
| Rotation speed(r/m) | 3000 | |
| Governor system | Mechanical | |
| Starting mode | 12V DC | |
| Filter system | Air filter, fuel filter, oil filter | |
| Cooling type | External cooling by river water or sea water | |
| Heat exchanger( L) | 5 | |
| Sea water filter | Available | |
| Sea water pump suction(M) | 2 | |
| Muffler | Water-cooled | |
| Fuel consumption(g/kw.h) | ≤195 | |
| Oil capacity(L) | 2 | |
| Alternator | Model | FD4 US brand high efficiency energy saving type |
| Brand | FD | |
| Rated power(KW) | 5 | |
| Excitation mode | Brushless, self-excitation | |
| Voltage regulation | Auto regulation | |
| Number of phase | Single phase, three wire | |
| Number of pole | 2 | |
| Rotation speed(R/M) | 3000 | |
| Temperature rise(℃) | 125 | |
| Cooling type | Air-cooled | |
| Insulation grade(stator/rotor) | H/H | |
| Voltage regulation range w/o load | ≥95%~105% | |
| Steady-state voltage deviation | Less ±1% | |
| Interference factor | TIF | |
| IP grade | IP23 | |
| Control panel | Model | OM588 |
| Manufacturer | OUMA | |
| Output terminal | Terminal post connection | |
| Installation | Remote cable connected | |
| Auto function | Manual/auto protection/shutdown, water temperature alarm, oil pressure alarm | |
| Parameter display | AC voltage, frequency, running hour, charging voltage | |
| Optional | External remote controller |
Exhibitions for Global Market
The air-cooled diesel generator can have optional wheels and hand kits, Electric start or manual starting.Small-sized diesel generator sets includes open type and silent type.Our Portable 5kw Water Cooled Diesel Marine Generator adopt different diesel engines and brushless generators.Generally adopt 1-cylinder&4-stroke&air-cooled engine, low fuel consumption, high reliability;It is easy to maintain as adopting brushless A.C.Generator and CDI ignition system.
JHSBJDHV
air-cooled diesel generator are quick-starting, stable-running, little vibration, low noise, light weight, small volume, compact structure, suitable for areas on mining, factory, working on field, engaging in construction and army as movable power or electric power in ship, Portable 5kw Water Cooled Diesel Marine Generator also suitable for areas on animal husbandry, fishery, forest, orchard, guesthouse and business as standby power.
JSHFDKJ
