Home>Products>air-cooled diesel generator>Air Cooled DEUTZ Diesel Generator

Air Cooled DEUTZ Diesel Generator
- DEUTZ
Air Cooled DEUTZ
- Original Air Cooled DEUTZ Diesel Generator
- One set Air Cooled DEUTZ Diesel Generator
- Negotiation
- Within 5 working days
- paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
- 97
-
Shandong Brawny Industrial Co.,Ltd2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
Product Description
Air Cooled DEUTZ Diesel Generator
1) Engine: Air cooled Deutz engine
2) Alternator brand: Wantong brushless, Stamford or Leroy Somer
3) Rated output: 5-200kw
4) Voltage: 400/230V, 220/110V
5) Frequency: 50Hz or 60Hz
6) Digital control panel
Features:
1) Consumption of fuel of air-cooling diesel engine is lower than water-cooling engine
2) The trouble is lower by 27% than water cooling diesel engine
3) It can be well started and work reliably even under -35°C. It is easy to
maintain and keep because of low number of components compare to as water cooling
system and having a low maintenance cost
Packing:
plywood case or wooden case
Parameter
Model | Prime Power | Engine model |
Engine power(kw) | Fuel consumption |
Cylinder *Bore*Stroke (Qty*mm*mm) |
Displacement (L) |
|||
KW/KVA | Prime | Standby | g/kw.h | L/h | |||||
WT-D7F | 5 | 6 | F1L511 | 5.7 | 6.27 | 240 | 1.61 | 1×100×105 | 0.825 |
WT-D11F | 8 | 10 | F2L511 | 11.5 | 12.65 | 240 | 3.25 | 2×100×105 | 1.65 |
WT-D14F | 10 | 13 | F2L912D | 14 | 17 | 238 | 3.92 | 2×100×120 | 1.88 |
WT-D17F | 12 | 15 | F2L912D | 14 | 17 | 238 | 3.92 | 2×100×120 | 1.88 |
WT-D22F | 16 | 20 | F3L912D | 24 | 29 | 232 | 6.55 | 3×100×120 | 2.828 |
WT-D28F | 20 | 25 | F3L912D | 24 | 29 | 232 | 6.55 | 3×100×120 | 2.828 |
WT-D33F | 24 | 30 | F4L912D | 32 | 38 | 228 | 8.58 | 4×100×120 | 3.77 |
WT-D40F | 30 | 38 | F4L913D | 34 | 40 | 228 | 9.12 | 4×100×120 | 3.77 |
WT-D50F | 36 | 45 | F4L912TD | 41 | 48 | 228 | 11 | 4×100×120 | 3.77 |
WT-D55F | 40 | 50 | F6L912D | 48 | 60 | 228 | 12.88 | 6×100×120 | 5.655 |
40 | 50 | BF4L913D | 47 | 55 | 218 | 12.05 | 4×102×125 | 4.086 | |
40 | 50 | F4L413FR | 51 | 57 | 223 | 13.38 | 4×125×130 | 6.381 | |
WT-D62F | 45 | 56 | F6L913D | 51 | 65 | 228 | 13.68 | 6×102×125 | 6.128 |
WT-D70F | 50 | 63 | F6L912TD | 61 | 72 | 228 | 16.36 | 6×100×120 | 5.655 |
50 | 63 | BF4L413FR | 65 | 72 | 216 | 16.52 | 4×125×130 | 6.381 | |
WT-D88F | 64 | 80 | BF6L913D | 74 | 88 | 223 | 19.41 | 6×102×125 | 6.128 |
64 | 80 | F6L413F | 77 | 85 | 223 | 20.2 | 6×125×130 | 9.572 | |
WT-D110F | 80 | 100 | BF6L913CD | 84 | 105 | 223 | 22.04 | 6×102×125 | 6.128 |
80 | 100 | F8L413F | 103 | 114 | 216 | 26.17 | 8×125×130 | 12.763 | |
WT-D124F | 90 | 113 | F8L413F | 103 | 114 | 216 | 26.17 | 8×125×130 | 12.763 |
WT-D140F | 100 | 125 | BF6L513LR | 113 | 126 | 204 | 27.12 | 6×125×145 | 10.676 |
100 | 125 | BF8L513 | 120 | 138 | 212 | 29.93 | 8×125×130 | 12.763 | |
WT-D154F | 112 | 140 | BF8L513C | 129 | 148 | 212 | 32.17 | 8×125×140 | 13.738 |
WT-D165F | 120 | 150 | BF6L513LRC | 141 | 157 | 204 | 33.84 | 4×125×145 | 10.676 |
WT-D176F | 128 | 160 | BF8L513 | 147 | 162 | 212 | 36.66 | 8×125×130 | 12.763 |
128 | 160 | F10L413F | 147 | 162 | 216 | 37.36 | 10×125×130 | 15.953 | |
WT-D220F | 160 | 200 | BF8L513LC | 190 | 196 | 205 | 45.82 | 8×125×140 | 13.738 |
WT-D275F | 200 | 250 | BF12L513L | 234 | 245 | 205 | 56.44 | 12×125×130 | 19.144 |



The air-cooled diesel generator can have optional wheels and hand kits, Electric start or manual starting.Small-sized diesel generator sets includes open type and silent type.Our Air Cooled DEUTZ Diesel Generator adopt different diesel engines and brushless generators.Generally adopt 1-cylinder&4-stroke&air-cooled engine, low fuel consumption, high reliability;It is easy to maintain as adopting brushless A.C.Generator and CDI ignition system.
JHSBJDHV
air-cooled diesel generator are quick-starting, stable-running, little vibration, low noise, light weight, small volume, compact structure, suitable for areas on mining, factory, working on field, engaging in construction and army as movable power or electric power in ship, Air Cooled DEUTZ Diesel Generator also suitable for areas on animal husbandry, fishery, forest, orchard, guesthouse and business as standby power.
JSHFDKJ
