100KVA/80KW trailer mounted diesel generator
- [标签:pinpai]
6bt5.9-g2
- Original 100KVA/80KW trailer mounted diesel generator
- One set 100KVA/80KW trailer mounted diesel generator
- Negotiation
- Within 5 working days
- paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
- 191
- Shandong Brawny Industrial Co.,Ltd2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
Product Description
100KVA/80KW trailer mounted diesel generator
Detail specs of 100KVA/80KW trailer mounted diesel generator as follows:
Prime Power | 100KVA/80KW |
Standby Power | 110KVA/85kw |
Rated Current | 144A |
Dimension | 2150*830*1350mm |
Weight | 1100kg |
Engine No. | 6bt5.9-g2 |
Cooling way | Water cooled |
Intake | Turbocharged and air air after cooled |
No. of Cylinders | 6 |
Rated Speed | 1500/1800RPM |
Bore*Stroke | 102*120 mm |
Compression Ratio | 17.5:1 |
Displacement | 5.9L |
Frequency | 50Hz ( 60Hz is available) |
Power Factor | 0.8 Lagging |
Voltage | 380-415V |
Protection Degree | IP23 |
Governor |
Electric |
Overall description:
1. Water cooled radiator, the fans driven by belt, with safety shield.
2. 24 V Battery charging Alternator
3. Alternator:Single bearing Alternator,IP22 Grading Protection, H Insulation degree
4. Shock absorber
5 Dry air filter,Fuel filter,Oil filter
6. Power output circuit breaker
7. LCD display
8. 24V battery and battery connection cables
9 Exhaust pipe,Corrugated shock tube,flange,Muffler set
10. Maintenance manuals
11. Lubrication System
Basic components of this Genset
*Diesel engine with 3 filters and other accessories
*AC synchronous generator*Water tank & radiator assembly*The cooling fan and fan guard*Heavy duty steel channel base frame*Genset control system*Genset circuit breaker*24V DC starting motor and charging alternator*Vibration-damping supports between engine/alternator and the base frame*Base fuel tank for 8 hours operation Standard accessory list 1.Fuel connecting pipes 1 set2.12V DC dry type battery c/w battery cables 2 sets3.Industrial type silencer c/w stainless steel flexible exhaust bellows 1 set4.Shock absorption rubbers 4 pcs5.The tool kit and 1 set of manuals (English version). Operating conditions of generator set 1.Altitude: ≤1500 m.2.Ambient Temperature: -15℃~50℃ .3.Relative air humidity: ≤90% .4.The site can't has electric conduction dust and corrosive gas that destroies metal insulation.5.The site can't has explosion danger. We make and export different type of diesel generator sets: 1. Open type 2. Rain proof and silent canopy 3. Trailer type4. Containler type
Contact person:
Fen
Tel: 86 0710 2789730
Mobile: 86 18062818287
Whatsapp: +86 18062818287
Skype: kerry32155
Linkediin:https://www.linkedin.com/in/%E8%8A%AC-%E5%91%A8-4361b2b4?trk=hp-identity-name
The air-cooled diesel generator can have optional wheels and hand kits, Electric start or manual starting.Small-sized diesel generator sets includes open type and silent type.Our 100KVA/80KW trailer mounted diesel generator adopt different diesel engines and brushless generators.Generally adopt 1-cylinder&4-stroke&air-cooled engine, low fuel consumption, high reliability;It is easy to maintain as adopting brushless A.C.Generator and CDI ignition system.
JHSBJDHV
air-cooled diesel generator are quick-starting, stable-running, little vibration, low noise, light weight, small volume, compact structure, suitable for areas on mining, factory, working on field, engaging in construction and army as movable power or electric power in ship, 100KVA/80KW trailer mounted diesel generator also suitable for areas on animal husbandry, fishery, forest, orchard, guesthouse and business as standby power.
JSHFDKJ
