Product Description
15kva open frame diesel generator
Main features:
1.The lightest and smallest among the gensets with same outpout
2.Full automatic generator-protection system
3.Special dual protection system
4.Unique unloading system for stopping the generator
5.Steady frequency-governing ratio ≤ 3%, complying with military standard
6.Automatic transfer switching,remote monitoring, to realize guardless by human
Options: Universal-direction Wheel, ATS, R485 Standard Communication Connection, Electric self-suction Pump, Heater.
Technical Parameters:
Model |
LP15000TA3 |
Rated frequency Hz |
50 60 |
Rated output power kVA |
13 14 |
Max. power kVA |
14 15.5 |
Rated voltage V |
400/230 416/240 |
Rated current A |
18.8 19.5 |
Phase No. |
Three |
Power factor cosφ |
0.8 lag |
Insulation |
F |
Pole No. |
2 |
Exciting way |
Brush, exciting-self voltage-constant with AVR |
Panel type |
Intelligent/common |
Output socket |
Three-phase socketsingle-phase socket |
DC12V output |
12V, 8.3A |
DimensionsL×W×H mm |
870×630×700 |
Net weight Kg |
195 |
Noise 7mdB(A) |
78 |
Structure type |
half-closed |
Engine model |
LP2V88 |
Type |
V-twin, two-cylinder, four-stroke, DI |
Cylinder No. bore ×stroke mm |
2-88×72 |
Total displacement ml |
870 |
Rated power kW/ rated speed r/min |
13/3000 14/3600 |
Compressed ratio |
20:1 |
Cooling way |
Air-cooled |
Lubricating way |
Pressure & splashing |
Starting way |
Electric |
Fuel used |
0 summer,-10 winter,-35 cold winter,light diesel |
Oil used |
SAE10W30CD grade above |
Lubricating oil capacity L |
1.7 |
Starting motor capacity V-kW |
12V 1.4kW |
Dynamo capacity V-A |
12V 8.3A |
Battery capacity V-Ah |
12V 45AH |
Fuel consumption g/kW.h |
≤285 ≤300 |
Fuel tank capacity of the generator L |
25 |
Continuous operation time of the generator H |
8 7.5 |
The air-cooled diesel generator can have optional wheels and hand kits, Electric start or manual starting.Small-sized diesel generator sets includes open type and silent type.Our 15kva open frame diesel generator adopt different diesel engines and brushless generators.Generally adopt 1-cylinder&4-stroke&air-cooled engine, low fuel consumption, high reliability;It is easy to maintain as adopting brushless A.C.Generator and CDI ignition system.
JHSBJDHV
air-cooled diesel generator are quick-starting, stable-running, little vibration, low noise, light weight, small volume, compact structure, suitable for areas on mining, factory, working on field, engaging in construction and army as movable power or electric power in ship, 15kva open frame diesel generator also suitable for areas on animal husbandry, fishery, forest, orchard, guesthouse and business as standby power.
