63kVA Super Silent Diesel Engine Generating Set 220V
- silent diesel generator set
silent diesel generator set
- China
- One set 63kVA Super Silent Diesel Engine Generating Set 220V
- sales2@f-engine.com
- Within 5 working days
- paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
- 37
-
Shandong Brawny Industrial Co.,Ltd2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
Product Description
| 63kVA Super Silent Diesel Engine Generating Set 220V | |||||||||
| 1. Specification of genset | |||||||||
| Gensets model | TPD63C6 | ||||||||
| Prime power | 50KW/63KVA | ||||||||
| Rated Voltage(V) | 440/220 | ||||||||
| Rated frequency(HZ) | 60 | ||||||||
| Rated Speed(RPM) | 1800 | ||||||||
| Power Factor | 0.8(lagging) | ||||||||
| Dimensions(mm) (L×W×H) | 1700x730x1285 | Open type | |||||||
| Genset Weight(kg) | 700 | ||||||||
| Dimensions(mm) (L×W×H) | 2400x1000x1560 | Silent type | |||||||
| Genset Weight(kg) | 1270 | ||||||||
| 2. Specification of diesel engine | |||||||||
| Engine model | 4BTA3.9-G2 | ||||||||
| Output power | 65kW/82kVA | ||||||||
| Number of Cylinders | 4 | ||||||||
| Cylinder arrangement | In-line | ||||||||
| Cycle | Four stroke | ||||||||
| Aspiration | Turbo/Aftercooled | ||||||||
| Bore×Stroke (mm×mm) | 102x 120 | ||||||||
| Displacement (Liter) | 3.9 | ||||||||
| Compression Ratio | 16.5:1 | ||||||||
| Speed Governor | Mechanical | ||||||||
| Cooling System | Forced Water Cooling Cycle | ||||||||
| Total lubrication system capacity (L) | 11 | ||||||||
| Fuel Consumption at 100% Load (g/kw.h) | 220 | ||||||||
| Starting Method | DC24V electrical starting | ||||||||
| 3. Specification of alternator | |||||||||
| Alternator brand | Stamford | ||||||||
| Alternator model | UCI224D | ||||||||
| Rated power | 50KW/63KVA | ||||||||
| Number of Phase | 3 | ||||||||
| Connecting Type | 3 Phase and 4 Wires | ||||||||
| Number of Bearing | 1 | ||||||||
| Protection Grade | IP23 | ||||||||
| Altitude | ≤1000m | ||||||||
| Exciter Type | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire | ||||||||
| Insulation Class | H | ||||||||
| Telephone Inf63kVA Super Silent Diesel Engine Generating Set 220Vce Factor (TIF) | ≤50 | ||||||||
| THF | ≤2% | ||||||||
| Voltage Regulation, Steady State | ≤±1% | ||||||||
| Transient State Voltage | ≤-15%~+20% | ||||||||
Product Description
Our Services
Packaging & ShippingPayment terms: 30% T/T as deposit, 70% balance be paid before shipment or100% irrevocable L/C at sight
Delivery time: 5-25 days against deposit (according to specific project)Company Information
silent diesel generator set are usually used in the environments wth stringent requirements for noise such as hospital,school,banks,hotels or other commercial sites.63kVA Super Silent Diesel Engine Generating Set 220V The soundproof generator set is made of the standard unit with mute cover.The mute cover can be removed and facilitate the care and maintenance.
HJHBGVK
silent diesel generator set is powered by 1000 series (produced by Tianjin Lovol Diesel Engine Works) diesel engine.The engien has the feature of good power performance,safety ,63kVA Super Silent Diesel Engine Generating Set 220V low fuel consumption and good reliablility ,silent diesel generator set generator set is widely used as prime or standby power supply in national defence ,telecommunication,fieldwork,building,supermarket ,industril and mining factory ,oil field ,highway,harbour and so on.
