3kva generator Sweden 230 volt generator recoil start air-cooled gasoline generator
- Gasoline Generator
Gasoline Generator
- China
- One set 3kva generator Sweden 230 volt generator recoil start air-cooled gasoline generator
- sales2@f-engine.com
- Within 5 working days
- paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
- 75
Product Description
3kva generator Sweden 230 volt generator recoil start air-cooled gasoline generator
Detailed Specification recoil start air-cooled gasoline generator
1. X3800 3kw generator
2. round frame avr generator
3. 3kw recoil start air-cooled gasoline generator
4. 230 volt gasoline generator
|
E N G I N E |
ITEM | X3800 recoil start air-cooled gasoline generator | |
| Engine model | TD170F | ||
| Engine type | Air-cooled 4-stroke, OHV, 25°inclined single cylinder | ||
| Bore×stroke mm | 70×54 | ||
| Displacement ml | 210cc | ||
| Compression ratio | 8.5:1 | ||
| Max power kW/rpm | 3.9/3600 | ||
| Rated power kW/rpm | 3.7/3600 | ||
| Max torque N.m/rpm | 11.5/3000 | ||
| Ignition system | Transistorized magneto | ||
| Starting system | Recoil start | ||
| Air cleaner | Foam element | ||
| Oil capacity L | 0.6 | ||
| Lowest fuel consumption g/(kw.h) | ≤395 | ||
|
G E N E R A T O R |
Max power | 3kw | |
| Rated power | 2.8kw | ||
| Rated voltage V | 12(DC) | 12v | |
| Rated circuit A | 8.3(DC) | 8.3dc | |
| Voltage regulation | AVR | ||
| Rated frequency Hz | 50/60 | ||
| Phase | DC | ||
| Power factor COSφ | 1 | ||
| Material of winding | Copper wire | ||
| Insulation level grade | F | ||
| Sound pressure level (rated power at 7meter) | 70 | ||
| Fuel tank capacity L | 15 | ||
| Continuous work time at rated power/full tank hrs | 7.5 | ||
| Dimension L×W×H mm | 610×460×465 | ||
| N.W/G.W kg | 46/48 | ||
| Fuel | gasoline, petrol | ||
| 20FT, 40FT set | 240, 495 | ||
Detailed pictures of X3800 recoil start air-cooled gasoline generator :
Types of engines for recoil start air-cooled gasoline generator :
Packing System for recoil start air-cooled gasoline generator :
Exhibition recoil start air-cooled gasoline generator:
FAQs:
1. Are you a trading company or a factory?
R: We are an experienced OEM & ODM factory.
2. What's the MOQ for this 3kva recoil start air-cooled gasoline generator ?
R: It's 10sets, but for a sample order 1 set is acceptable.
3. What's your payment terms?
R: T/T, L/C, Cash etc.
4. Whta's your port of shipment?
R: Chongqing, Shanghai, Shenzhen or any other port as request.
5. What about the LADE TIME?
R: In 20~35days after deposit payment confirmed.
6. How could you manage the quality?
R: All machines have to go through 5 strict checks in the whole process.
Welcome to send inquiry to me!!!
Digital Control Panel
3kva generator Sweden 230 volt generator recoil start air-cooled gasoline generator The new gasoline genset model is equipped with digital control system and remote control.Gasoline Generator Some control units of the generator sets are on the multi function display.
JHDBCHJD
Real-time Data Display
Gasoline Generator A monitor of the panel will display the real-time working data of the generator set such as its output voltage, Frequency, running time, battery voltage etc. 3kva generator Sweden 230 volt generator recoil start air-cooled gasoline generator Besides, the running trouble of the generator will also be displayed on the panel.
SDCHBKSH
Low Oil Alarm System
Gasoline Generator Before the oil level drops to the limited level, the generator set will top automatically. 3kva generator Sweden 230 volt generator recoil start air-cooled gasoline generator The whole set can be restarted only if the oil is refilled.
DFDVFD
New AVR
Gasoline Generator The AVR (Automatic Voltage Regulator) not only can smooth the output but also can provide reasonable protection against the overload of the whole set,3kva generator Sweden 230 volt generator recoil start air-cooled gasoline generator thus avoid damage to the set.
SVFVDF
Electrical Starter
Gasoline Generator A convenient electric starter gets the new gasoline generator up and running quickly.
